High-Impact Wear Resistance Ultra-High Manganese Steel Castings

Home / Products / Casting / High-Impact Wear Resistance Ultra-High Manganese Steel Castings

High-Impact Wear Resistance Ultra-High Manganese Steel Castings

These highly wear-resistant castings are manufactured from alloy steel with an ultra-high manganese content, representing a high-performance material developed specifically for environments involving large-scale equipment, high-strength loads, and severe impact-abrasion. By increasing the manganese content and optimizing the alloy composition, the product achieves superior work-hardening capabilities and impact resistance.

During operation, the surface of the casting rapidly hardens upon impact, forming a highly wear-resistant layer, while the interior retains excellent ductility and toughness; this results in a "wear-resistant-as-it-wears" characteristic.

The product is ideally suited for large-scale mining and heavy-duty crushing equipment, capable of withstanding high-energy impacts and the demands of continuous, long-term operation.

Contact Us Contact Us
PREV：Modified High-Manganese Wear Steel Castings NEXT：High-Chromium Cast Iron Castings For Cement Industry
  • Specifications
  • Description
  • Contact Us
NO. Kinds Brand number C Si Mn Cr Mo Ni Cu S P AK (J/cm²) HRC σb (MPa) Metallographic Structure
1 Medium Carbon Medium Chromium I ZG30Cr5MoRE 0.25~0.35 0.3~1.0 0.3~1.0 4.5~5.5 0.2~1.0 — — ≤0.045 ≤0.045 ≥25 ≥45 — M+B+C
2 Medium Carbon Medium Chromium II ZG40Cr5MoRE 0.35~0.45 0.3~1.0 0.3~1.0 4.5~5.5 0.2~1.0 0.1~0.4 ≤0.1 ≤0.045 ≤0.045 ≥20 ≥48 — M+B+C
3 Medium Carbon Low Alloy Steel ZG40Cr5MoNiRE 0.3~0.5 1.1~1.6 0.3~1.0 1.2~1.8 0.2~0.6 1.4~1.8 — ≤0.04 ≤0.04 ≥30 ≥40 — M+F
4 Low Carbon High Alloy Steel ZG20Cr9NiMo 0.15~0.35 ≤1.0 0.3~1.0 8~10 0.4~0.8 0.5~1.0 — ≤0.045 ≤0.045 ≥40 ≥40 — M+C
5 Cr-Ni-Mo Alloy Steel ZG45Cr3NiMoMn-RE 0.4~0.50 0.3~0.8 0.6~1.2 2.0~3.2 0.3~0.5 — — ≤0.04 ≤0.04 ≥20 ≥50 — M+C
6 90 Chromium Alloy Steel ZG90Cr6MoMn 0.85~0.95 0.4~0.8 0.4~0.8 5~8 0.2~0.4 — — ≤0.045 ≤0.045 ≥7 ≥50 — M+C
7 Conventional High Manganese Steel ZGMn13 1.1~1.4 0.3~1.0 11~14 — — — — ≤0.06 ≤0.10 ≥147 HB≥229 637 A+C
8 Modified High Manganese Steel ZGMn13Cr2MoVTiNbRe 1.1~1.3 0.3~1.0 11~14 1.8~2.5 — Ti:0.2~0.4 — ≤0.06 ≤0.10 ≥80 ≥240 — A+C
9 Super High Manganese Steel ZGMn17Cr2 1.1~1.4 0.3~1.0 16~19 5~2.5 — 4~6 — ≤0.06 ≤0.10 ≥50 ≥260 — A+C
10 Heat Resistant Steel ZG20Cr26Ni5 ≤0.20 ≤0.20 ≤0.20 1.0~2.0 ≤0.5 11~14 — ≤0.04 ≤0.04 — — 590 A+F
11 HH ZG20Cr26Ni12 0.2~0.5 ≤0.20 ≤0.20 24~28 ≤0.5 19~22 0~1.2 ≤0.045 ≤0.045 — — 490 A+F
12 HK ZG40Cr25Ni20 0.35~0.45 ≤0.20 ≤0.20 24~28 ≤0.5 0~1.0 0.8~1.2 ≤0.045 ≤0.045 — — 440 A+F
13 High Chromium Cast Iron KmTBCr15Mo2 2~2.8 ≤1.2 0.5~1.0 23~27 0.2~2.5 0~1.5 0~2.0 ≤0.06 ≤0.10 ≥53 — — M+A+C
14 High Chromium Cast Iron KmTBCr20Mo2 2~3.0 ≤1.2 0.5~1.0 13~18 1.5~2.5 0~1.5 1~2.0 ≤0.06 ≤0.10 ≥3 ≥58 — M+A+C
15 High Chromium Cast Iron KmTBCr26 2~3.0 ≤1.2 0.5~1.0 23~28 0.1~1.0 0~1.0 0~1.0 ≤0.06 ≤0.10 ≥55 — — M+A+C
16 High Chromium Cast Steel ZGCr12SiMn-GT 1.0~2.0 ≤1.2 0.5~2.0 12~14 0.1~1.0 0~1.0 0~1.0 ≤0.06 ≤0.10 ≥3.2 ≥55 — M+A+C
17 High Chromium Cast Steel ZGCr15SiMn-GT 1.0~2.0 ≤1.2 0.5~2.0 15~17 0.1~1.0 — — ≤0.06 ≤0.10 ≥3.5 ≥55 — M+A+C

Product Features:
Ultra-high manganese alloy formulation for outstanding wear resistance;
Rapid work-hardening rate;
High impact resistance and resistance to cracking;
Suitable for large-scale, heavy-duty equipment;
Long service life, reducing replacement costs.

Applications:
Large-scale mining crushing equipment, iron and steel metallurgical equipment, cement production lines, and large grinding mills.
